Dantherm SD 4500-5800-7000-9000 – desiccant dehumidifiers
Industrial drying – desiccant
A series of four powerful and energy-efficient adsorption dehumidifiers with a wide range of air flow rates with insulated casing suitable for both commercial and industrial applications. They have several features that can be tailored to specific needs with the possibility of pre- and post-treatment and control according to specific control requirements and energy optimisation.
View other desiccant dehumidifiers or see our full range of industrial dehumidifiers suitable for multiple applications.
Dantherm SD 9000 desiccant dehumidifier
|
Dantherm SD desiccant dehumidifers for vertical farming video
|
Principles of adsorption drying
|
Key features
- Effective dehumidification in all temperatures (-30°C to +60°C)
- Particularly suitable at low temperatures
- High dehumidification capacity adapted to every need
- Can dehumidify down to 2% RH
- Insulated double-jacketed cabinet
- Energy-efficient solutions with high-efficiency rotors and EC fans
- Can be supplied with thicker rotor (increased dehumidification capacity)
- PTC (Positive Temperature Control) regeneration coil, eliminating the risk of overheating and enabling stepless capacity control
Product specifications
| Specifications | Units | SD 4500 |
|---|---|---|
| Process air (EC) | m³/h | 4,500 |
| Reg air (EC) | m³/h | 1,500 |
| Capacity(20°C/60% RH) | kg/h | 24.6 |
| Voltage | V | 3 x 400 |
| Effect | kW | 40.8 |
| Effect reg | kW | 36 |
| Audio | dB | 72 |
| Weight | kg | 410 |
| Dimensions (l x w x h) without support/handle | mm | 2193 x 1277 x 1311 |
| Dimensions (l x w x h) without dimensions (t - dry air) | Ømm | 500 |
| Target (p - process air) | Ømm | 630 |
| Target (v - wet air) | Ømm | 315 |
| Target (r - regeneration air) | Ømm | 315 |
| Steering | PLS | |
| SD communication** | Modbus TCP/IP | |
| *BacNet as an option | ||
| Max* | Yes | |
| Specifications | Units | SD 5800 |
|---|---|---|
| Process air (EC) | m³/h | 5,800 |
| Reg air (EC) | m³/h | 1,400 |
| Capacity(20°C/60% RH) | kg/h | 29.3 |
| Voltage | V | 3 x 400 |
| Effect | kW | 44.8 |
| Effect reg | kW | 44 |
| Audio | dB | 72 |
| Weight | kg | 520 |
| Dimensions (l x w x h) without support/handle | mm | 2193 x 1277 x 1311 |
| Dimensions (l x w x h) without dimensions (t - dry air) | Ømm | 500 |
| Target (p - process air) | Ømm | 630 |
| Target (v - wet air) | Ømm | 315 |
| Target (r - regeneration air) | Ømm | 315 |
| Steering | PLS | |
| SD communication** | Modbus TCP/IP | |
| *BacNet as an option | ||
| Max* | Yes | |
| Specifications | Units | SD 7000 |
|---|---|---|
| Process air (EC) | m³/h | 7,000 |
| Reg air (EC) | m³/h | 2,200 |
| Capacity(20°C/60% RH) | kg/h | 43 |
| Voltage | V | 3 x 400 |
| Effect | kW | 65.5 |
| Effect reg | kW | 60 |
| Audio | dB | 72 |
| Weight | kg | 540 |
| Dimensions (l x w x h) without support/handle | mm | 2193 x 1277 x 1311 |
| Dimensions (l x w x h) without dimensions (t - dry air) | Ømm | 500 |
| Target (p - process air) | Ømm | 630 |
| Target (v - wet air) | Ømm | 315 |
| Target (r - regeneration air) | Ømm | 315 |
| Steering | PLS | |
| SD communication** | Modbus TCP/IP | |
| *BacNet as an option | ||
| Max* | Yes | |
| Specifications | Units | SD 9000 |
|---|---|---|
| Process air (EC) | m³/h | 9,000 |
| Reg air (EC) | m³/h | 2,500 |
| Capacity(20°C/60% RH) | kg/h | 50 |
| Voltage | V | 3 x 400 |
| Effect | kW | 80 |
| Effect reg | kW | 72 |
| Audio | dB | 72 |
| Weight | kg | 550 |
| Dimensions (l x w x h) without support/handle | mm | 2193 x 1277 x 1311 |
| Dimensions (l x w x h) without dimensions (t - dry air) | Ømm | 500 |
| Target (p - process air) | Ømm | 630 |
| Target (v - wet air) | Ømm | 315 |
| Target (r - regeneration air) | Ømm | 315 |
| Steering | PLS | |
| SD communication** | Modbus TCP/IP | |
| *BacNet as an option | ||
| Max* | Yes | |
Suitable for
- Agriculture
- Archives and preservation
- Commercial buildings
- Construction
- Data centres and telecoms
- Emergency services
- Food and beverage
- Industrial, factories and production
- Military and aerospace
- Museums and galleries
- Pharmaceutical and scientific
- Transport and logistics
- Warehouses and storage
- Waterworks
